Gallagher Gallagher S100 Solar power fence energiser including battery (12 V - 7,2 Ah)
Gallagher Gallagher S100 Solar power fence energiser including battery (12 V - 7,2 Ah)
SKU:346304
Low stock: 10 left
Regular price
£449.00 GBP
Regular price
Sale price
£449.00 GBP
Unit price
/
per
Taxes included.
Couldn't load pickup availability
- Operates for 3 weeks without direct sunlight
- Super-strong, drop-proof, waterproof housing
- Quick and easy to install
- Built-in lightning protection
- Includes game or wildlife mode that keeps ticking vigorously even at night
The S100 is the ultimate portable energiser solution, storing 1,0 J and capable of powering up to 6 mile/10km or 10 hectare of Multi-wire fence. This fence energiser comes complete with a rechargeable battery and solar panel.
The S100 is quick and easy to install and convenient to transport. This robust and highly portable unit makes a great alternative to battery- powered systems.
Specifications:
- Maximum output voltage (V): 9000
- Charging energy (J): 1.0
- Maximum impulse energy (J): 0.74
- Solar panel (Watt): 7
- Number of earthing rods required: 2 x 1 m
- No vegetation (km) (recommended): 10
- Light vegetation (km) (recommended): 5
- Dense vegetation (km) (recommended): 3
- Fence surface (ha) (recommended): 4
| Warranty (years): | 3 |
|---|---|
| IPX classification: | IPX4 |
| Recommended number of earth stakes: | 2x1m |
| Normal - slow pulse mode: | ? |
| Auto power conservation to prevent damage to battery: | ? |
| Device indicator light On/Off: | ? |
| Battery LED (indicator): | ? |
| Battery safemode: | ? |
| Grid area (Hec/Acre): | 4/10 |
| Multi (3) Wire Fence distance - Recommended (km): | 3 |
| Multi (2) Wire Fence distance - Ideal conditions (km): | 10 |
| Multi (2) Wire Fence distance - Light conditions (km) : | 5 |
| Single Wire Fence distance - Ideal conditions (km): | 30 |
| Output Energy (J): | 0,74 |
| Stored Energy (J): | 1 |
| Voltage with 100 Ohm (V): | 1000 |
| Output with 500 Ohm (V): | 3600 |
| Maximum output Voltage: | 9600 |
| Avg. current draw Battery (V/mA): | 12/43 |
| Days operational with no daylight: | ^20 days |
| Night savings option: | ? |
| Built-in solar panel: | 7W |
| Fence connection wire included: | ? |
| Rechargeable Battery included: | ? |
| Recommended Battery (minimal advised): | VRLA 12V-7.2Ah |
| Recommended replacement Battery (Part No.): | 000442 / 033931 |
| Suitable Stand (height): | 007509 (88cm), 730003 (50cm) |
| Weight (Kg): | 5,0 |
